WATERLASE Fractional Handpiece

The Future of Skin Resurfacing

Address esthetic appearance, wrinkles, and uneven skin textures with Waterlase Fractional Skin Resurfacing.

Waterlase Fractional HP


  • FDA-cleared for safe, effective, and in-demand dermatologic
    skin resurfacing therapy
  • Waterlase perforates the thin outer layer of skin (epidermis) and heats the underlying skin (dermis), which stimulates the growth of collagen — a protein that improves skin firmness and texture
  • Promotes even skin resurfacing, allowing surrounding untreated skin to signal extracellular matrix for growth and wound healing
  • Handpiece fits comfortably and ergonomically in either hand
  • No local or topical anesthetic required for many procedures
  • Reduced risk of complications compared to more invasive
  • Proven wavelength — effective full-face treatment while
    reaching the dermis layer
  • Single-use disposable applicators for patient safety

*Waterlase iPlus software version 2.3.11 or later and firmware version 2.1.2 or later. Dentist/Clinician must know and adhere to state guidelines and regulations when purchasing and using this accessory. Check with your state and or local government for required permits or other applicable laws. The Fractional Handpiece is for extraoral skin resurfacing only, and is not intended for intraoral use.

Contact Us to Learn More

Fractional Handpiece

How does it work?

The Waterlase Fractional Handpiece treats only fractions of the skin by perforating the epidermis with 10 microbeams in a row.

  • “Pixelated” perforations (about 250μm diameter) are made in the skin as the clinician moves the handpiece in a single pass.
  • Coagulation of the dermal collagen is produced, which increases cutaneous contraction after healing.
  • Surrounding tissue is left intact and undamaged.
  • Rapid re-epithelialization in less than 24-48 hours, minimizing downtime.

Patient-Pleasing Results

Increase Referrals

Enhance your portfolio of cosmetic services with the Waterlase Fractional Handpiece and your patients will want to tell a friend.

Waterlase Fractional Handpiece

Technical Specifications

Laser medium Er,Cr YSGG
Wavelength 2780 nm
Operating modes pulsed
Pulse width, μs 60 μs, 700 μs
Pulses per second 15 Hz
Total energy/pulse: 100 – 400 mJ
Energy per spot: 10 – 40 mJ
Spot Diameter: 250um
Spot spacing: 0.9 mm & 1.0mm* in Y direction (*based on movement speed of 15 mm/second)
Fluence per spot: 20 - 82 J/cm22
Surface coverage: 5% (single pass; *based on movement speed of 15 mm/second)

Please contact your local distributor for additional product information outside of the United States.
